Maxon DC Motor - Specifications:
Motor Type: DC motor with precision winding.
Nominal Voltage: 24V (based on the "024" in the model number).
Outer Diameter: Likely around 41 mm (as suggested by the "41" in the model's name).
Length: Approx. 22 mm (as indicated by "022").
Winding Configuration: Customized (based on the additional numbers like "-400").
No-Load Speed: Typically ranges between 2000-10,000 RPM depending on winding configuration.
No-Load Current: Generally, in the range of a few milliamps to tens of milliamps.
Torque Constant: Around 10-50 mNm/A depending on exact specifications.
Efficiency: High, typical of Maxon motors, often above 70-85%.
Bearings: Precision ball bearings.
Advantages: Ironless Rotor Design, High Reliability, Customizability, Ease of Integration, Fast Response Time, Exceptional Torque-to-Weight Ratio.
Applications: Medical Technology, Robotics, Aerospace, Automation and Industrial Equipment, Automotive, Instrumentation and Testing, Consumer Electronics.
Maxon EC Motor - Specifications:
Motor Type: Brushless DC motor (electronically commutated).
Motor Size: Outer diameter: Range from ~4 mm (micro) to 90 mm or more
Voltage Range: Typical operating voltages: 6V, 12V, 24V, 48V, and higher.
Power Output: Power ranges from a few watts (low power for micro motors) to several hundred watts.
Speed: Nominal speeds: Can exceed 100,000 rpm in some models.
Torque: Nominal torque: Varies from a few mNm to over 500 mNm, depending on the motor size.
Efficiency: High efficiency, typically over 80% in most models.
Commutation: Sensorless or with Hall sensors for position feedback.
Bearing Type: High-precision ball bearings for durability and low friction.
Thermal Properties: Temperature range: Often from -40°C to +100°C or higher, depending on insulation class.
Integrated Options: Encoders (digital or analog) for precise control.
Advantages: Long Lifespan, High Performance, Energy Efficient, Customizability, Smooth Operation, Durability in Extreme Environments.
Applications: Medical Technology, Robotics, Aerospace, Automation and Industrial Equipment, Automotive.
